AWS Cognito SSO Configuration (Confidential)

• Troubleshooting

AWS Cognito SSO enables users to log in using credentials from an AWS Cognito User Pool through OAuth 2.0 and OpenID Connect (OIDC).

This configuration supports Confidential Clients, which use both Client ID and Client Secret for secure backend authentication.

Configuration Fields

Provider Name

• Definition: A human-readable name for this AWS Cognito SSO configuration instance.
• Example: AWS Cognito SSO, Company Cognito, User Pool Authentication
• Why it matters: Helps identify this configuration in logs and UI.
• Note: This is a display name and doesn't affect authentication.

Client Type

• Definition: Defines whether the application is public (no client secret) or confidential (requires client secret).
• Options: Public | Confidential
• Example: Confidential
• Why it matters: Determines security level and authentication flow. Confidential clients securely store secrets.
• Note:
  • Use Public for lightweight, client-side apps.
  • Use Confidential for backend or server-based applications.

Authority

• Definition: AWS Cognito User Pool domain that issues tokens.
• Example: https://cognito-idp.us-east-1.amazonaws.com/us-east-1_ABC123DEF
• Why it matters: Specifies which Cognito User Pool OpenMetadata authenticates against.
• Note: Use the format https://cognito-idp.{region}.amazonaws.com/{user-pool-id}.

Public Key URLs

• Definition: URL(s) where AWS Cognito publishes its public keys for token verification.
• Example: ["https://cognito-idp.us-east-1.amazonaws.com/us-east-1_ABC123DEF/.well-known/jwks.json"]
• Why it matters: Used to verify JWT token signatures from Cognito.
• Note: Typically auto-discovered; manual setup is rarely required.

Token Validation Algorithm

• Definition: Algorithm used to validate JWT token signatures.
• Options: RS256 | RS384 | RS512
• Default: RS256
• Example: RS256
• Why it matters: Must match the signing algorithm used by AWS Cognito.
• Note: Cognito defaults to RS256.

OIDC Client ID

• Definition: The App Client ID from your AWS Cognito User Pool.
• Example: 1a2b3c4d5e6f7g8h9i0j1k2l3m4n5o6p
• Why it matters: Identifies your application during authentication.
• Note: Found in AWS Console → Cognito → User Pools → App Integration → App Clients.

OIDC Client Secret

• Definition: Secret key for confidential client authentication.
• Example: a1b2c3d4e5f6g7h8i9j0k1l2m3n4o5p6q7r8s9t0
• Why it matters: Required for secure server-to-server communication.
• Note:
  • Generated in Cognito → User Pool → App Client → Generate Secret.
  • Store securely and rotate regularly.
  • Only visible for Confidential client types.

OIDC Request Scopes

• Definition: Scopes requested from AWS Cognito during authentication.
• Default: openid email profile
• Example: openid email profile aws.cognito.signin.user.admin
• Why it matters: Defines what user information OpenMetadata can access.
• Note: Must match scopes configured in your Cognito app client.

OIDC Discovery URI

• Definition: AWS Cognito’s OIDC metadata endpoint.
• Example: https://cognito-idp.us-east-1.amazonaws.com/us-east-1_ABC123DEF/.well-known/openid-configuration
• Why it matters: Allows OpenMetadata to auto-discover endpoints for tokens and authorization.
• Note: Replace {region} and {user-pool-id} with your values.

OIDC Use Nonce

• Definition: Prevents replay attacks by ensuring each authentication request is unique.
• Default: true
• Example: true

OIDC Preferred JWS Algorithm

• Definition: JWT signature verification algorithm.
• Default: RS256
• Example: RS256

OIDC Response Type

• Definition: Expected response type during OAuth authentication.
• Default: id_token
• Options: id_token | code
• Example: code
• Why it matters: The code flow is recommended for Confidential Clients.
• Note: Authorization Code flow provides enhanced security.

OIDC Disable PKCE

• Definition: Whether to disable Proof Key for Code Exchange (PKCE).
• Default: false
• Example: false
• Why it matters: PKCE protects against code interception attacks.
• Note: Should generally remain enabled (false).

OIDC Max Clock Skew

• Definition: Maximum allowed time difference when validating tokens.
• Example: 0 (seconds)

OIDC Client Authentication Method

• Definition: Method used to authenticate the client with AWS Cognito.
• Default: client_secret_basic
• Options: client_secret_basic | client_secret_post
• Example: client_secret_basic
• Why it matters: Must align with your app client configuration.

OIDC Token Validity

• Definition: Token expiration duration in seconds.
• Default: 0 (inherits provider default)
• Example: 3600
• Why it matters: Controls session duration and refresh timing.

OIDC Tenant

• Definition: Cognito User Pool ID.
• Example: us-east-1_ABC123DEF
• Why it matters: Uniquely identifies your Cognito User Pool.

OIDC Server URL

• Definition: Your OM server url.
• Example: https://yourapp.company.com.
• Why it matters: Specifies the URL at which OM is hosted.

OIDC Callback URL

• Definition: Redirect URI where Cognito sends authentication responses.
• Example: https://yourapp.company.com/callback
• Note:
  • Must be registered in Cognito → User Pool → Hosted UI → Allowed Callback URLs.
  • Always use HTTPS in production.

OIDC Max Age

• Definition: Maximum authentication age before re-login is required.
• Example: 3600 (seconds)

OIDC Prompt

• Definition: Controls how Cognito prompts users during authentication.
• Options: none | login | consent | select_account
• Example: login
• Note:
  • login: Always prompt for credentials
  • none: Use existing session silently (SSO)

OIDC Session Expiry

• Definition: Session expiration duration (seconds).
• Default: 604800 (7 days)

JWT Principal Claims

• Definition: Claims used to identify users.
• Example: ["cognito:username", "email", "sub"]
• Note: Common Cognito claims include cognito:username, email, sub, preferred_username.

JWT Principal Claims Mapping

• Definition: Maps JWT claims to OpenMetadata user attributes.
• Example: ["email:email", "name:name", "firstName:given_name"]
• Note: Use format "openmetadata_field:jwt_claim".

Admin Principals

• Definition: Users with administrative privileges in OpenMetadata.
• Example: ["admin@company.com", "superuser@company.com"]

Principal Domain

• Definition: Default domain for user principals.
• Example: company.com

Enforce Principal Domain

• Definition: Enforces domain restriction for user logins.
• Default: false
• Example: true

Enable Secure Socket Connection

• Definition: Enables SSL/TLS for secure connections.
• Default: false
• Example: true
• Note: Must be enabled in production environments.

Summary Table

Troubleshooting

If users are automatically logged out and unable to log in again due to a bad authentication configuration, you can reset the security setup using the following command:

After executing the command, restart the server. The authentication values from your YAML or Helm chart will then be reapplied on startup. The following tiles detail how to apply this configuration across Docker, Kubernetes, and Bare Metal deployments:
